Modules |
13+13 |
|
Sockets |
2 Tomas 2P+TTL 16A/250V~ / 1 Toma interblocante 2P+T 16A/250V~ / 1 Toma interblocante 3P+T 16A/380V~ / 1 Toma interblocante 3P+N+T 32A/380V~ / 1 pulsador de emergencia |
|
Measurements |
866x330x150mm |
|
Entries |
5XØ40-Ø32 + 4XØ25-Ø20 / 2XØ40-Ø32 + 2XØ25-Ø20+ 1XØ50-Ø40 |
|
Degree of protection |
IP65 |
|
Shock-proof |
IK08 |
|
Dimensional stability |
-25ºC+85ºC |
|
Glow wire |
650ºC |
|
Standards |
EN 60439-4, EN 62208 |
|
Protection |
1 bobina de emisión / 1 IGA 4P 80A / 1 diferencial 2P 40A 30mA / 1 diferencial 4P 63A 30mA / 3 magnetotérmicoS 2P(reducido) 16A / 1 magnetotérmico 3P 16A / 1 magnetotérmico 4P 32A |
