Sockets |
2P+T: 2 (16A Bloqueo) / 3P+T: 1 (32A Bloqueo), 1 (16A Bloqueo) / 3P+N+T: 1 (63A Bloqueo) |
|
Measurements |
900x950x450mm |
|
Degree of protection |
IP40 |
|
Shock-proof |
IK09 |
|
Dimensional stability |
-25ºC + 85ºC |
|
Ball pressure |
70ºC |
|
Glow wire |
650ºC |
|
Standards |
EN 60439-3, EN 60439-4, EN 61439-1 |
|
Self-extinguishing level |
HB(UL94) |
|
Protection |
I.G.A: 1 (100A) / Diferencial: 1 (4/63/300), 1 (4/40/30) / II Polos: 2 (16A) / III Polos: 1 (32A), 1 (16A) / IV Polos: 1 (63A) |
